4 axle 70T-90T U type dump trailer
4 axle 70T-90T U type dump trailer
4 axle 70T-90T U type dump trailer
4 axle 70T-90T U type dump trailer
4 axle 70T-90T U type dump trailer
4 axle 70T-90T U type dump trailer
4 axle 70T-90T U type dump trailer
4 axle 70T-90T U type dump trailer
Max Payload:
30 ton
Axle
16T FW, with ABS
Material:
Steel

4 axle 70T-90T U type dump trailer

Dump semi trailer adopt advanced design concept. For the tipper trailer box, we adopt high strength steel to make it durable whenload the sand or small stones or rocks, especially under the off road condition.
Share:
Product Details
Automobile and construction machinery manufacturers
Dump trailers are more versatile than dump trucks. They have some of the same features as dump trucks, such as powerful lift mechanisms and wide beds, so they can handle the same types of materials in much the same way. But with a wider range of designs and styles available, dump trailers have more customisation than dump trucks!
Product advantages
Product Advantages
Advantage
Low engine sound
Advantage
High horsepower
Advantage
Low fuel consumption
Advantage
More stable
Advantage
Good maintenance
technical parameter
product technical parameter
item value
Use Truck Trailer
Type Semi-Trailer
Material Steel
Size 10300*3050*3870mm
Max Payload 30 ton
Place of Origin China
Brand Name HUAJUN
Product name 47M3 4Axle Rear-Tipper Trailer
van body side wall 6mm, floor 8mm; U-shape body; NM 450
axle 16T FW, with ABS
leaf spring 120mm width*12pieces*16mm thickness, on rear 3axles
suspention CIMC HUAJUN reinfored type on 3axles
landing gear 30T, SAF HLD30, two sides operation
kingpin 3.5", KZ1016, bolted type
tyre 12.00R20-18PR, RLB777, Double Coin
hand jonit straight-direct-type
chamber T30/30 on 2axles, 4pcs; 30 on 1axle, 2pcs
application
Automobile and construction application
Why Choose ?

The design of a tipper trailer varies depending on its purpose: side dumping or unloading. Maintaining torsional stiffness on the road and during unloading is critical for all models of tipper trailers.

Our trailers are made of all-steel structure, with the advantages of good matching, solid structure, beautiful shape, reliable braking, safe use, smooth driving, high loading potential, easy maintenance and durability
